Hydraulic Press Tool Kit


Item No.:CH121423-A
Hydraulic Cylinder 17pcs Set

Description:

* This tool enables controlled, professional and safe extraction of very tight-fitting injection nozzles in conjunction with a special pull spindle, a Injector Nozzle Puller with extraction bridge and a Hydraulic-Pump with manometer.
* The Hydraulic-Cylinder with shoulder nut together with a special pull spindle is placed onto the extraction bridge instead of a mechanical drive. The special manometer of the Hydraulic Pumps or ensures that the applied force can be checked during the extraction process.

Content:
* Pull Spindele M14*1.5(240mm) 1 pcs
* Pull Spindele M14*1.5(315mm) 1 pcs
* Pull Spindele M17*1(240mm) 1 pcs
* Pull Spindele M17*1(315mm) 1 pcs
* Pull Spindele M25*1(240mm) 1 pcs
*
Distance ring 1 pcs

¡@

¡@

¡@

¡@
